- LED lighting with 0-10V dimming
- Full compliance with NEC 330, NEC 725, and UL 1569
- Cable reverse wound on reel for ease of pulling and installation
Southwire MC-PCS Duo power and control/signal cable 250-ft 12 / 4 Stranded Aluminum MC (Metal Clad) Cable
Southwire’s MC-PCS Duo is suitable for use as circuits for branch power distribution in commercial, industrial, institutional and multi-residential buildings as well as power, lighting, control and signal circuits. It works with LED lighting with 0-10V dimming. This cable is constructed with 12 AWG CU type THHN/THWN power and ground conductors along with a control conductor assembly composed of a 30 mil PVC jacket covering two 16 AWG CU type TFN control conductors. The phase conductors, ground and control conductor assembly are cabled together and a binder tape bearing the print legend is wrapped around the assembly. Aluminum interlocking armor is applied over the taped assembly. Yellow stripe/blocks are printed on the outside of the armor and the print legend is applied in black print on every 4th yellow stripe/block.
- LED lighting with 0-10V dimming
- Full compliance with NEC 330, NEC 725, and UL 1569
- Cable reverse wound on reel for ease of pulling and installation
- Lightweight aluminum interlocked armor
- Power, lighting, control and signal circuits
| General |
| Series Name |
MC-PCS Duo power and control/signal cable |
Wire Gauge |
12 |
| Sub-Brand |
N/A |
Conductor Material |
Aluminum |
| Type |
MC cable |
Direct Burial |
No |
| Voltage Rating |
600 |
Number of Strands |
1 |
| Number of Conductors |
4 |
Ground Wire |
Green insulated copper |
| Stranded or Solid |
Stranded |
Armor Material |
Aluminum |
| Dimensions |
| Cable Length (Feet) |
250 |
| Features |
| Commercial/Residential |
Commercial |
Moisture Resistant |
No |
| Fire Resistant |
No |
Shielded |
No |
| Maximum Amperage |
25 |
UV Resistant |
No |
